PANORAMIC

Beam & Wash ZoomLed

7x40W 4IN1 RGBW LED

Motorized linear zoom system

Outstanding color macro effect

0~100% smooth dimming

Variable strobe effects

TECHNICAL DATA

Compact moving head with Wash&Beam Zoom function.

Controllable with DMX 512 digital signal or automatically with or without music. DMX-controlled Beam Zoom with a beam angle of 6° to 45° and the Moving Wash has a total of 7 x 40 Watt RGBW LEDs which enable a powerful light output as well as infinitely variable color mixing.

An adjustable Dimmer and strobe effects allow for creative and ever-changing light shows. LCD display to check the parameters.

Fast, silent and precise EYE is the ideal product for events, bars, discos, theatres, concerts, etc.

Light Sources: 7x40W 4IN1 RGBW LED

Beam Angle: 6°~ 45°

Motorized linear zoom system

Outstanding color macro effect

Dimmer: 0~100% smooth dimming

Variable strobe effects

Fast, quiet operation and flicker free

DMX Channel: 17 /22CH

Control Modes: DMX512/mater-Slave/Auto Run/Music/RDM

Pan/Tilt

Pan/Tilt: 540°/ 270°

Pan/Tilt Resolution: 8/16 bit

Power Consumption: 250W

Power Voltage: AC 100-240V, 50/60Hz

DATA Display: LCD Display

Data In/Out socket: 5-pin XLR sockets

Power Socket: Power con in/out

Protection Rating: IP20

Dimension: 258*178*334 mm

Net Weight: 5.5 Kgs

Flight case packing(6 in 1): 910x570x550mm

Carton packing(1 in 1): 310x230x420mm
